Apex C2276MEN Derrick Tape Chrome Clad 100 Ft Steel

Product Description

The APEX C2276MEN is a 100-foot derrick tape designed for precision linear measurement in demanding field and industrial applications. The blade carries a chrome clad finish over a steel substrate, providing corrosion resistance and long-term legibility under heavy use. The E2 blade style is graduated in both SAE and metric units, giving technicians and field crews a single tool for dual-standard jobsites. Four arms support the tape housing, and the compact overall footprint keeps the unit manageable during extended use. This tape is built for professionals who need accurate, repeatable measurements at distance.

Derrick tapes are standard equipment on drilling rigs, communication towers, and tall structures where vertical or extended horizontal measurement is required. The C2276MEN suits trades and crews that work at elevation or measure long spans where a standard tape would be impractical. The chrome clad blade resists the moisture, oils, and grit common on active job sites. The dual SAE and metric graduation eliminates the need to carry separate tapes when work orders specify different unit systems.

Key Features

• 100-foot chrome clad steel blade for extended-range measurement
• E2 blade style with SAE and metric dual graduation
• 0.25-inch blade width for flexibility and smooth retraction
• Four-arm housing construction for stability and controlled payout
• Chrome clad finish resists corrosion and abrasion in field conditions

Compatibility

Designed as an OEM-style replacement or direct-use derrick tape suitable for standard derrick tape applications requiring a 100-foot SAE and metric graduated steel blade.

Installation Notes

Derrick tapes are deployed and retrieved by hand; no power tools are required. Always inspect the blade for kinks, nicks, or delamination before use, as blade damage can cause inaccurate readings or sudden retraction failure. Keep the tape free of sharp bends during payout and retrieval to preserve blade integrity. Store the tape in a dry location when not in service to extend blade and housing life.

Technical Specifications

• Blade Length: 100 feet
• Blade Width: 0.25 inches
• Blade Material: Steel
• Blade Finish: Chrome Clad
• Blade Style: E2
• Measurement Type: SAE and Metric
• Number of Arms: 4
• Overall Length: 9.1 inches
• Overall Width: 7.4 inches
• Overall Height: 1.7 inches
• Weight: 3 pounds
• UPC: 037103454737

Standard Information

• Brand: APEX
• Manufacturer Part Number: C2276MEN
