Apex C18CCSN Locking Pliers C-clamp 18 Inch Nickel Plated

Product Description

The APEX C18CCSN is an 18-inch C-clamp style locking pliers built from alloy steel with a nickel-plated finish. Designed for heavy-duty gripping, clamping, and holding tasks, these pliers lock securely onto workpieces to free up both hands during fabrication, repair, or assembly work. The C-clamp jaw profile allows clearance around irregular shapes and flanged surfaces that standard jaw styles cannot reach. With a jaw capacity of 9.5 inches and a jaw length of 11 inches, the C18CCSN handles oversized workpieces that smaller locking pliers cannot accommodate. Licensed tradespeople and experienced mechanics reach for this tool on structural, mechanical, and sheet metal applications.

The C18CCSN is suited for commercial and industrial environments where large-format clamping is required. Pipefitters, ironworkers, welders, and HVAC sheet metal mechanics will find the wide jaw opening and extended length useful when positioning ductwork, pipe assemblies, structural members, or heavy plate stock. The nickel-plated finish resists corrosion in shop and field conditions. This tool is sold individually and is appropriate for any trade shop needing a full-size locking clamp for repetitive or heavy clamping tasks.

Key Features

• C-clamp jaw style with 9.5-inch jaw capacity for large or irregular workpieces
• 11-inch jaw length and 5.6-inch jaw width provide broad clamping surface
• Alloy steel construction for strength and durability under high clamping force
• Nickel-plated finish for corrosion resistance in field and shop environments
• 18-inch overall length delivers extended reach and leverage
• Jaw thickness of 0.9 inches maintains rigidity at maximum opening

Compatibility

Designed as a general-purpose locking C-clamp pliers for use across trade and industrial applications requiring large-jaw clamping capacity.

Installation Notes

Locking pliers do not require installation but should be adjusted to the workpiece before engaging the locking mechanism to avoid jaw slip or workpiece damage. Keep the adjustment screw threads clean and lightly lubricated for consistent locking action. Inspect the jaw teeth and locking mechanism before each use and remove the tool from service if the lock does not hold under load.

Technical Specifications

• Overall Length: 18 inches
• Jaw Type: C-Clamp
• Jaw Capacity: 9.5 inches
• Jaw Length: 11 inches
• Jaw Opening: 9 inches
• Jaw Thickness: 0.9 inches
• Jaw Width: 5.6 inches
• Material: Alloy Steel
• Finish: Nickel Plated
• Weight: 3.17 pounds
• UPC: 037103217271

Standard Information

• Brand: APEX
• Manufacturer Part Number: C18CCSN
