Apex 9150LN Replacement Tape Measure Reel 50 Ft 2 Arm

Product Description

The APEX 9150LN is a replacement reel designed for Crescent Lufkin tape measures, providing a direct swap-out solution when the original reel housing or blade assembly reaches end of service life. The reel accepts a 0.5-inch-wide blade in a 50-foot length and uses a 2-arm frame configuration. Overall assembled length is 9.2 inches. This is a service-level component used by tradespeople, tool repair technicians, and facilities maintenance crews to extend the usable life of an existing tape measure rather than replacing the full unit.

This replacement reel is suited for jobsite and shop environments where tape measures see heavy daily use. The 2-arm reel design is standard across a range of Crescent Lufkin 50-foot tape models. Installation is a bench-repair task typically performed by a tool technician or experienced tradesperson during routine tool maintenance. No special shop equipment is required beyond basic hand tools and a clean work surface.

Key Features

• 50-foot blade capacity with 0.5-inch blade width
• 2-arm reel frame for straightforward drop-in replacement
• Overall length of 9.2 inches, height of 1.9 inches, width of 6.2 inches
• Sold individually — one reel per unit
• Designed for Crescent Lufkin tape measure service and repair

Compatibility

Designed as a replacement reel for Crescent Lufkin tape measures that use a 50-foot, 0.5-inch-wide blade with a 2-arm reel configuration. Verify blade width and arm count against the existing unit before installation.

Installation Notes

Disassemble the tape measure housing completely before removing or installing the reel. Handle the blade carefully during transfer to avoid kinking or edge damage. Follow the original manufacturer assembly sequence when reassembling the housing to ensure proper blade retraction tension. Inspect all housing components for wear before reassembly.

Technical Specifications

• Blade Length: 50 feet
• Blade Width: 0.5 inches
• Number of Arms: 2
• Overall Length: 9.2 inches
• Overall Height: 1.9 inches
• Overall Width: 6.2 inches
• Weight: 1.2 pounds
• Sold As: Each

Standard Information

• Brand: APEX
• Manufacturer Part Number: 9150LN
