Apex 893823 Pass-thru Mechanics Tool Set 3/8 in Drive

Product Description

The APEX 893823 is a Pass-Thru mechanics tool set built around a 3/8 inch drive, 6-point ratchet-and-socket system designed to increase productivity and access in tight-clearance work. The ratchet requires as little as 5 degrees of arc swing to move fasteners, compared to 30 degrees for standard ratchets. By eliminating the drive tang, the ratchet is 40 percent stronger than conventional designs and up to 50 percent thinner, giving technicians the ability to reach fasteners in confined areas. The included adapter accepts standard sockets and drive tools, extending the versatility of the set.

This tool set is suited for automotive, fleet, and equipment service applications where standard deep-well sockets are cumbersome or where bolt length varies. The Pass-Thru socket design uses a thin-wall profile to seat on nuts regardless of how far the bolt extends, eliminating the need to swap between standard and deep-well sockets during a job. It is a practical choice for professional mechanics and technicians working in production or shop environments.

Key Features

• 5-degree arc swing ratchet for operation in restricted spaces
• Tang-free ratchet design rated 40 percent stronger than standard ratchets
• Ratchet head up to 50 percent thinner than conventional models for improved access
• Thin-wall Pass-Thru sockets accommodate nuts on bolts of any length without swapping to deep-well sockets
• Integrated socket-to-ratchet fit reduces overall tool height and increases torque transfer
• Included adapter allows use of standard 3/8 inch drive sockets and accessories

Compatibility

Designed as an OEM-style replacement and upgrade set for 3/8 inch drive mechanics tool applications. Compatible with standard 3/8 inch drive sockets and accessories via the included adapter.

Installation Notes

This tool set is intended for use by professional mechanics and service technicians. Before servicing any fasteners on electrical or fuel system components, disconnect power or shut off fuel supply per applicable safety procedures. Inspect all ratchet and socket connections for proper seating before applying torque. Do not use impact drivers with these sockets unless explicitly rated for impact use.

Technical Specifications

• Drive Size: 3/8 inch
• Point Configuration: 6 point
• Weight: 4.19 pounds
• UPC: 082171893827
• Unit of Measure: Each

Standard Information

• Brand: APEX
• Manufacturer Part Number: 893823
