Apex 80449 Triple Square Bit Socket 3/8 Drive 6MM

Product Description

The APEX 80449 is a 6 MM triple square bit socket designed for 3/8 inch drive applications. The base socket is constructed from heat-treated alloy steel for durability and extended tool life. The bit itself is machined from S2 steel, which provides the strength needed to drive triple square fasteners without rounding or deforming the recess. At 2.088 inches in length and weighing 0.15 pounds, this socket is sized for use in tight engine bays and chassis work where access is limited. It is sold individually and suits professional technicians working on European vehicles.

Triple square fasteners, also known as XZN fasteners, appear frequently on European vehicle platforms in applications such as brake caliper bolts, transmission drain plugs, driveshaft bolts, and cylinder head fasteners. This socket is well suited for shop use by automotive technicians performing maintenance or repair on vehicles where triple square drive hardware is specified by the manufacturer. The 3/8 inch drive connection is compatible with standard 3/8 inch ratchets, extensions, and torque wrenches already common in most automotive shops.

Key Features

• Heat-treated alloy steel base socket for durability and long service life
• S2 steel bit for maximum drive strength on triple square fasteners
• 6 MM triple square profile for European vehicle fastener applications
• 3/8 inch drive connection for compatibility with standard drive tools
• Compact 2.088 inch length suited for confined work areas

Compatibility

Designed for use with triple square fasteners commonly found on European vehicles. Compatible with standard 3/8 inch drive ratchets, extensions, and torque wrenches.

Installation Notes

This socket is intended for use by automotive technicians familiar with triple square fastener applications. Before beginning any fastener removal or installation, ensure the vehicle is safely secured and the relevant system is depressurized or de-energized as required. Use the correct drive torque wrench when specified torque values are called out in the vehicle service manual. Do not use impact drivers unless the socket and bit are rated for impact use.

Technical Specifications

• Drive Size: 3/8 inch
• Bit Profile: Triple Square
• Bit Size: 6 MM
• Length: 2.088 inches
• Overall Length (package): 3.15 inches
• Base Socket Material: Heat-Treated Alloy Steel
• Bit Material: S2 Steel
• Weight: 0.15 pounds
• Sold As: Each
• UPC: 099575804496

Standard Information

• Brand: APEX
• Manufacturer Part Number: 80449
