Apex 30227 Ball Bearing Taper Mount Chuck 0.625 Maximum Capacity 2-5/8 Sleeve Diameter 4-5/16 Close Length

Product Description

The Apex 30227 ball bearing taper mount chuck is a reliable tool with a 0.625 maximum capacity. This product features a one-piece sleeve design that eliminates common cracks found in other models. The through-hardened sleeve teeth along with hardened nose and keyholes provide excellent wear resistance.

• Ball bearing taper mount chuck
• Ball bearing construction maximizes gripping force and drilling accuracy
• Jaws center-ground for straightness and alignment

Product Highlights

This chuck ensures precision and durable performance. It maintains accuracy with a TIR of 0.003 inches at half capacity. The chuck has a minimum capacity of 0.04 inches and a maximum capacity of 0.625 inches. It comes with a 3JT mount and K4 key number.

Product Information

Standard Information

• Brand: Apex
• MPN: 30227
• Category: Tools & Home Improvement
• Sub-Category: Accessories

Technical Specifications

• Maximum Capacity: 0.625 inches
• Minimum Capacity: 0.04 inches
• Sleeve Diameter: 2-5/8 inches
• Close Length: 4-5/16 inches
• Open Length: 3-17/64 inches
• Mount Type: 3JT
• Key Number: K4
• Weight: 3.198 pounds
