Apex 05026N Half Round File Second Cut 10 Inch

Product Description

The APEX 05026N is a half round file with a second cut tooth pattern, designed for general-purpose filing, deburring, and shaping of metal components. The flat face works convex surfaces while the rounded back handles concave curves and inside radii. At 10 inches of cutting length and an overall length of 12.62 inches, it provides solid reach and control in hand filing applications. The file body measures 0.96 inches wide and 0.26 inches thick. Constructed from steel with a hard-stamped marking style, it delivers consistent cut performance across ferrous and non-ferrous metals. The file is sold without a handle.

This file is suited for metal fabrication, pipefitting, HVAC equipment service, and general mechanical work where controlled material removal is needed. The second cut pattern sits between bastard and smooth cuts, making it effective for intermediate finishing work after rough shaping. It handles tasks such as smoothing weld seads, fitting pipe flanges, cleaning up threads, and shaping sheet metal edges. Trades including plumbers, pipefitters, HVAC technicians, and general mechanics commonly carry this style of file as a standard bench tool.

Key Features

• Second cut tooth pattern for intermediate material removal and finishing
• Half round profile addresses both flat and curved work surfaces
• 10-inch file length with 12.62-inch overall length for extended reach
• Steel construction for durability across metal filing applications
• Hard-stamped markings for clear, permanent identification
• Sold individually without a handle, compatible with standard aftermarket file handles

Compatibility

Designed as a standard half round second cut file for use in general metal fabrication, pipefitting, and mechanical service applications where a 10-inch second cut file is specified.

Installation Notes

File use requires no power tools or electrical shutoff, but always secure workpieces in a vise before filing to prevent movement and injury. Wear safety glasses during all filing operations to protect against metal filings and debris. A handle should be installed before use to reduce the risk of injury from the exposed tang. Inspect the file for cracks or damage before each use and replace if the tooth pattern is worn smooth.

Technical Specifications

• File Cut: Second
• File Length: 10 inches
• Overall Length: 12.62 inches
• File Width: 0.96 inches
• File Thickness: 0.26 inches
• Material: Steel
• Marking Style: Hard Stamped
• Handled: No
• Weight: 0.49 pounds
• UPC: 037103218612

Standard Information

• Brand: APEX
• Manufacturer Part Number: 05026N
