ANVIL SC208N Series SC208 2 in. Stainless Steel Full Port Threaded 800# Ball Valve

Product Description

The ANVIL SC208N Series SC208 is a two-inch stainless steel full port threaded ball valve designed for high performance and durability. This ball valve is rated for a cold working pressure of eight hundred pounds and steam pressure of one hundred fifty pounds. Its body and ball are constructed from ASTM A351 Grade CF8 stainless steel, ensuring strength and corrosion resistance.

• Full port design for maximum flow capacity
• Blow-out proof stem for enhanced safety
• Compatible with cold working pressure and steam applications

Product Highlights

This valve is ideal for both residential and commercial plumbing applications where reliability is key. It is suitable for vacuum service down to twenty-nine inches of mercury.

Product Information

Standard Information

• Brand: ANVIL
• MPN: SC208N

Technical Specifications

• Material: Stainless Steel, Plastic
• Valve Type: Ball Valve
• Pressure Class: 150#, 800#
• Valve Size: 2 in
• Weight: 4.44 lb
• Length: 4.63 in
• Valve Operator: Lever Handle
• Valve Seat Material: RTFE
