Anvil 4352115800 Ball Valve 1 Inch Full Port 316 Ss

Product Description

The ANVIL 4352115800 is a 3-piece, full-port manual ball valve designed for 1-inch pipe systems requiring reliable isolation and flow control. The body, trim, and finish coating are all 316 stainless steel, making this valve well suited for corrosive media, high-purity fluid handling, and demanding industrial or mechanical piping applications. PTFE seats and seals provide low-friction operation and broad chemical compatibility. The 3-piece body construction allows the valve to be removed from the line for service or replacement without disturbing adjacent piping. A locking lever handle prevents inadvertent actuation in critical applications. Licensed plumbers and pipefitters are the primary installers of this type of valve.

This valve is used in residential and commercial plumbing, HVAC hydronic systems, process piping, and industrial fluid systems where a stainless steel shutoff is required. The full-port design minimizes pressure drop across the valve, which is important in flow-sensitive systems. FNPT x FNPT end connections make it compatible with standard threaded pipe assemblies. The locking lever is particularly useful in installations where accidental operation must be prevented, such as chemical feed lines or primary shutoffs in mechanical rooms.

Key Features

• 316 stainless steel body, trim, and finish for corrosion resistance in aggressive media
• Full-port design minimizes pressure drop and flow restriction
• 3-piece body allows in-line service and valve removal without cutting pipe
• PTFE seats and seals provide chemical resistance and low operating torque
• Locking lever handle prevents unintended valve actuation
• FNPT x FNPT end connections suit standard threaded pipe assemblies
• Meets ASME B16.34 standards for pressure-temperature rated valves

Compatibility

Designed as an OEM-style replacement or new-installation manual ball valve for 1-inch threaded pipe systems requiring 316 stainless steel construction and full-port flow characteristics.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter following applicable IPC and facility codes. Depressurize and drain the system completely before removing or installing any valve. Apply appropriate thread sealant to FNPT connections per the sealant manufacturer's instructions and the project specifications. Confirm that the valve's pressure-temperature rating is compatible with the system's operating conditions before placing in service.
