Anvil 4351012160 Steam Service Ball Valve 1/2 in Fnpt

Product Description

The ANVIL 4351012160 is a 1-piece stainless steel manual ball valve engineered for steam service applications. The body is constructed from 316 stainless steel, and the valve features a graphoil seal material rated for the elevated temperatures and pressures common in steam systems. The standard port design delivers reliable flow control, while the locking lever handle prevents unintended operation during service. This valve is installed by licensed plumbers and pipefitters working on steam distribution, condensate return, and similar high-temperature piping systems.

This valve is suited for residential and commercial steam service piping where a durable, corrosion-resistant shutoff is required. The FNPT x FNPT end connections allow straightforward threaded installation into 1/2 inch iron or steel pipe systems. The locking lever handle is particularly useful in mechanical rooms and boiler rooms where valve position must be secured between service intervals. The Nova seat material supports reliable sealing performance under steam service conditions.

Key Features

• 316 stainless steel body and handle for corrosion resistance in steam environments
• Graphoil seal material rated for high-temperature steam service
• Standard port, 1-piece construction for compact inline installation
• FNPT x FNPT end connections for threaded pipe assembly
• Locking lever handle prevents unintended valve actuation
• Nova seat material provides reliable shutoff in steam applications

Compatibility

Designed as an OEM-style replacement or new-installation ball valve for 1/2 inch threaded steam service piping systems.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable mechanical and plumbing codes, including ASME and local jurisdictional requirements. Depressurize and isolate the steam system completely before removing or installing any valve. Use appropriate thread sealant rated for steam service on FNPT connections. Verify valve orientation and flow direction prior to returning the system to service.
