Anvil 0870001203 MTM-40 Forged Carbon Steel Threadolet 1-1/4 x 5 - 8 in

Product Description

The Anvil 0870001203 is a forged carbon steel threadolet designed for fire protection applications. This product features a connection size of one and one-fourth by five to eight inches with a FNPT connection type.

• Manufactured with ASTM A53 material specifications.
• Rated for 300 psi for fire sprinkler systems.
• UL listed and FM approved for safety standards.

Product Highlights

This threadolet provides reliable performance in low pressure piping systems.

Product Information

Standard Information

• Brand: Anvil
• Part Number: MTM-40.114.5-8

Technical Specifications

• Model: MTM-40
• Item Name: Threadolet
• Connection Size: 1-1/4 x 5 - 8 in
• Connection Type: FNPT
• Inside Diameter: 1.49 in
• Length: 1-3/8 in
• Material: Carbon Steel
• Pressure Rating: 300 psi
• Schedule: SCH 5, 10, 40
• Standards/Certifications: cULus listed, FM approved, ANSI B1.20.1, NFPA 13 approved
• Applications: For fire protection and other low pressure piping systems
