Anvil 0870001187 Threadolet 1-1/4 x 2-1/2 - 3 in MPN

Product Description

The Anvil 0870001187 Threadolet is a forged carbon steel fitting designed for low pressure piping systems. This fitting is built for fire protection applications and conforms to industry standards. The product measures one and one-quarter by two and one-half to three inches and features FNPT connections. It is manufactured by Anvil International and meets chemical and physical requirements of ASTM A 53.

• SPF welded outlet fitting for high strength
• Rated for 300 psi in fire sprinkler systems
• UL listed and FM approved

Product Highlights

The Anvil Threadolet serves fire safety needs and is suitable for various low pressure piping systems.

Product Information

Standard Information

• Brand: Anvil
• Manufacturer: Anvil International

Technical Specifications

• Connection Size: 1-1/4 x 2-1/2 - 3 in
• Connection Type: FNPT
• Inside Diameter: 1.49 in
• Length: 1-3/8 in
• Material: Carbon Steel
• Pressure Rating: 300 psi
• Schedule: SCH 5, 10, 40
• Standards/Certifications: cULus listed, FM approved, ANSI B1.20.1, NFPA 13 approved
