Anvil 0870001138 MTM-40 Forged Carbon Steel Threadolet 1 x 2-1/2 - 4 in

Product Description

The Anvil 0870001138 is a forged carbon steel threadolet designed for fire protection and low pressure piping applications. This product is constructed using ASTM A53 compliant materials and features a strength-oriented design for durability. It is suitable for connection sizes ranging from one inch to two and a half inches to four inches, specifically utilizing FNPT connections.

• High strength forged steel construction
• Meets ASTM A 53 specifications
• UL listed and FM approved

Product Highlights

Ideal for fire protection systems, this threadolet is rated for three hundred psi and conforms to NFPA 13 standards.

Product Information

Standard Information

• Brand: Anvil International
• Part Number: MTM-40.1.212-4

Technical Specifications

• Connection Size: 1 x 2-1/2 - 4 in
• Connection Type: FNPT
• Item Name: Threadolet
• Material Specifications: ASTM A53, Grades A or B, Type E
• Material: Carbon Steel
• Method of Manufacturer: Forged
• Model: MTM-40
• Pressure Rating: 300 psi
• Schedule: SCH 5, 10, 40
• Applications: For fire protection and other low pressure piping systems
• Standards/Certifications: cULus listed, FM approved, ANSI B1.20.1, NFPA 13 approved
