Anvil 0870001013 MTM-40 SCH 5/10/40 Forged Carbon Steel Threadolet

Product Description

The Anvil 0870001013 is an MTM-40 forged carbon steel threadolet designed for low pressure piping systems, including fire protection applications. Its connection size measures one-half by one and one-quarter to two inches with FNPT type threading.

• Constructed from ASTM A53 compliant materials.
• Rated for 300 psi in fire sprinkler systems.
• UL listed and FM approved for reliability.

Product Highlights

Ideal for use with Schedule 5, 10, and 40 piping, the Anvil 0870001013 ensures strength and durability in various installations.

Product Information

Standard Information

• Brand: Anvil International
• Part Number: MTM-40.12.114-112

Technical Specifications

• Connection Size: 1/2 x 1-1/4 - 2 in
• Connection Type: FNPT
• Inside Diameter: 0.7 in
• Item Name: Threadolet
• Length: 1.063 in
• Material Specifications: ASTM A53, Grades A or B, Type E
• Material: Carbon Steel
• Method of Manufacturer: Forged
• Model: MTM-40
• Pressure Rating: 300 psi
• Schedule: SCH 5, 10, 40
