Anvil 0500072582 163 6 Pipe Protect Saddle

Product Description

The Anvil 0500072582 is a pipe covering protection saddle designed for high temperature applications. Made from carbon steel, this curved saddle supports insulated pipes and helps minimize heat loss. With a nominal size of six inches, it can withstand temperatures up to six hundred fifty degrees Fahrenheit. Installation of the saddle is recommended to be welded to the pipe for optimal performance.

• Curved design for effective coverage.
• Supports a maximum load of eighteen hundred pounds.
• Recommended for insulated high-temperature systems.

Product Highlights

This saddle provides a finished, weather-tight covering at all points of pipe support, ensuring reliable performance and protection of insulation.

Product Information

Standard Information

• Manufacturer: ASC Engineered Solutions
• Type: Curved

Technical Specifications

• Clamp Material: Carbon Steel
• Dimensions: 12 in L
• Domestic/Import: Domestic
• Finish: Plain
• Nominal Size: 6 in
• Series: FIG 163
• Temperature Rating: 650 deg F
