Anvil 0390028389 7072-PTD-2-1/2x1-1/2 Grooved Concentric Reducer

Product Description

The ANVIL 0390028389 7072-PTD-2-1/2X1-1/2 Grooved Concentric Reducer is a concentric type reducer made from carbon steel with an orange painted finish. It is designed for plumbing, mechanical, HVAC, industrial, fire protection, mining, and oil and gas applications. It features grooved x grooved end connections and conforms to ASTM A53 Grade B material specifications.

• Concentric type reducer
• Constructed from carbon steel with an orange painted finish
• Suitable for plumbing, HVAC, industrial, and fire protection applications

Product Highlights

Durable carbon steel reducer with grooved connections for versatile applications.

Product Information

Standard Information

• Brand: ANVIL
• Manufacturer Part Number: 0390028389

Technical Specifications

• Applicable Standard: NSF/ANSI 61, FM, LPCP, VDS, UL (Canada and US)
• Application: Plumbing, Mechanical, HVAC, Industrial, Fire Protection, Mining, Oil and Gas
• CPS COMM CODE: GRV_CONC_RED_PTD
• End Connection: Grooved x Grooved
• Finish: Orange Painted
• Master UPC (14): 69029110791
• Material: Carbon Steel
• Material Specification: ASTM A53 Grade B
• Process: Fabricated
• Schedule: 40 S
• Size A: 2-1/2 Inch
• Size B: 1-1/2 Inch
• Thickness: 0.203 Inch
• Type: Concentric
• Vendor UPC (12): 690291107917
• VENDOR Product No: 0390028389
• Item Weight (lbs): 1.3
• Brand: Gruvlok by Anvil International
• Diameter (Imp): 2-1/2"
• Diameter (Met): 62mm
• DiameterB (Imp): 1-1/2"
• DiameterB (Met): 40mm
• Manufacturer Number: 0390028389
