Anvil 0362038002 Black Steel Cross Fitting 1-1/4 in Class 3000

Product Description

The ANVIL 0362038002 is a forged carbon steel cross fitting with a black finish, designed for high-pressure piping systems in industrial and commercial applications. This four-way cross fitting connects branch lines in socket weld configurations, rated at 3000 psi and classified as Class 3000. At 1-1/4 inches in size, it is built for systems carrying liquids or gases under demanding pressure conditions. Licensed pipefitters and plumbers install this fitting where branch distribution is required along a primary run. The forged carbon steel construction delivers the structural integrity needed in process piping, steam, hydraulic, and high-pressure fluid systems.

This cross fitting is suited for industrial process lines, steam distribution systems, hydraulic installations, and high-pressure gas or liquid piping where a socket weld end connection is specified. It is a standard choice in plant maintenance, construction, and mechanical contracting environments where Class 3000 fittings are required by system design or code. The 1-1/4 inch size fits common branch-line configurations in both new construction and retrofit applications.

Key Features

• Forged carbon steel construction for high-pressure service integrity
• Class 3000 rated at 3000 psi for liquid and gas service
• Socket weld end connections for strong, full-penetration joints
• Black finish applied to forged body
• 1-1/4 inch fitting size for standard branch-line piping

Compatibility

Designed as an OEM-style replacement or new-installation fitting for Class 3000 socket weld piping systems using 1-1/4 inch forged carbon steel components.

Installation Notes

Installation of socket weld fittings is performed by licensed pipefitters or plumbers in accordance with applicable codes such as ASME B31.1 or B31.3. The system must be fully depressurized and isolated before fitting removal or installation. Socket weld joints require proper gap spacing between pipe end and socket shoulder before welding to allow for thermal expansion. Do not pressurize the system until all welds are inspected and approved per project specifications.
