Anvil 0300029105 Cast Iron 45 Degree Elbow 3 in Fpt

Product Description

The ANVIL 0300029105 is a 3-inch cast iron 45 degree elbow with female pipe thread (FPT) end connections and a black finish. Rated at 125 psi for both liquid and gas service, this Class 125 fitting redirects piping runs at a 45 degree angle in low-pressure systems. The cast iron construction provides durability in commercial and industrial environments. Licensed plumbers and pipefitters install this fitting in threaded piping assemblies where a moderate directional change is required without a full 90 degree turn. At 6.44 pounds, it is a solid, standard-weight fitting suited for permanent installations.

This elbow is used in residential and commercial plumbing, hydronic heating, gas distribution, and general industrial piping systems where threaded cast iron fittings are specified. The FPT connections on both ends accept standard NPT male-threaded pipe. Class 125 cast iron fittings are a common specification in low-pressure water and gas lines, fire protection piping, and steam condensate return systems. This fitting ships as a single unit.

Key Features

• 45 degree change of direction in threaded piping runs
• Cast iron construction for durability in permanent installations
• Black finish for corrosion resistance in typical service conditions
• FPT end connections on both ends accept standard NPT male pipe
• Class 125 rated to 125 psi for liquid and gas service
• 3-inch fitting size for larger-diameter piping assemblies

Compatibility

Designed as an OEM-style replacement or new-installation fitting for threaded cast iron piping systems using Class 125 fittings with standard NPT connections.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local plumbing codes and IFGC requirements for gas service. Shut off and depressurize the piping system completely before removing any existing fitting or making new connections. Apply an approved thread sealant or PTFE tape to all male NPT threads before assembly. Do not overtighten; cast iron fittings can crack under excessive torque.
