Antunes 801111302B Air Pressure Switch 0.1 to 4 in. w.c.

Product Description

The Antunes Air Pressure Switch with MPN 801111302B monitors air pressure in burner systems. It operates between 0.1 to 4 inches of water column (w.c.). This switch is suitable for high, low, or differential pressure applications. It is equipped with 1/8 inch NPT ports to connect seamlessly with existing setups. The device uses a SPDT design and can handle loads of up to 10 amps.

• 1/8 inch NPT ports for easy installation
• SPDT 10 Amp switch functionality
• Operates from 0.1 to 4 inches w.c.

Product Highlights

Reliable monitoring of air pressure for optimal burner operation.

Product Information

Standard Information

• Brand: Antunes
• Part Number: 801111302B

Technical Specifications

• Operating Pressure Range: 0.1 to 4 in. w.c.
• Port Size: 1/8 in. NPT
• Switch Type: SPDT
• Max Load Current: 10 Amps
