Anchor Fluid Power W61-32-32 SAE 4-Bolt Flange

Product Description

The Anchor Fluid Power W61-32-32 SAE 4-Bolt Flange is designed for high-pressure applications. This flange is suitable for use in various piping systems. It features a flat face and is constructed from carbon steel, ensuring durability and strength.

• Code 61 standard pressure rating
• Compatible with multiple port configurations
• Includes bolt kit with Buna o-ring

Product Highlights

This flange is ideal for connecting pipes in industrial settings. It is available in both carbon and stainless steel options and supports various connection types, making it versatile for many applications.

Product Information

Standard Information

• Brand: Anchor Fluid Power
• Part Number: 102182125

Technical Specifications

• Series: W61
• Material: Carbon Steel
• Pressure Rating: 3000 psi
• Pad Size: 2 in
• Port Type: Pipe Socket
• Face Type: Flat
• Bolt Thread: 1/2-13
• Bolt Spacing: 1 11/16 in x 3 1/16 in
