Goodman AMVE60DP1400 5.0 Ton Air Handler Multi-Position Variable Speed ECM Blower

Product Description

The Goodman AMVE60DP1400 Air Handler is a 5.0 ton unit designed for effective air distribution in various home sizes. Featuring a multi-position installation and a variable speed ECM blower motor, this air handler provides efficient comfort. With an all-aluminum evaporator coil and integrated ComfortBridge technology, it ensures optimal performance and ease of maintenance.

• Variable speed ECM blower motor
• All-aluminum evaporator coil
• ComfortBridge compatible

Product Highlights

This Goodman air handler includes features like a secure cabinet for noise reduction and durable construction. The unit's condensate management design prevents condensation and ensures smooth operations. A 10-year limited parts warranty is available upon product registration.

Product Information

Standard Information

• Brand: Goodman
• Model: AMVE60DP1400
• Type: Air Handler

Technical Specifications

• Capacity: 5.0 Tons
• Cooling BTU: 60000
• Blower Motor Type: Variable-Speed
• Voltage: 208/230 Volts
• Phase: 1
• Frequency: 60 Hz
• Cabinet Width: 24.5 inches
• Product Width: 24.5 inches
• Product Depth: 21 inches
• Product Height: 58 inches
• Shipping Weight: 177 pounds
• Installation Location: Indoor
• Refrigerant Type: R-410A
• Mount Type: Multi-Position
• Maximum Air Flow: 1640 CFM
• Minimum Air Flow: 1070 CFM
• Drain Outlet Diameter: 3/4 Inch
• Liquid Connection Size: 3/8 Inch
• Suction Connection Size: 7/8 Inch
• Minimum Circuit Ampacity: 8.6 Amps
• Recommended Breaker Size: 15/15 Amps
• Parts Warranty: 10 Limited Years
• Warranty: 10 Years
• ISO Certified: Yes
• AHRI Certified: Yes
