Amtrol SX-160V Extrol Expansion Tank 86 Gallon Volume

Product Description

The AMTROL SX-160V Extrol Expansion Tank is engineered for closed-loop hydronic systems, effectively managing pressure buildup and enhancing energy efficiency. This 86-gallon capacity tank is factory pre-charged to 12 PSIG, with a maximum working pressure of 100 PSIG and an operating temperature of up to 240°F. It accepts expanded fluid to control system pressure, making it suitable for heating applications.

• Factory pre-charged to 12 PSIG, adjustable to match minimum operating pressure at the tank location.
• Features a maximum working pressure of 100 PSIG and a maximum operating temperature of 240°F.
• Constructed with deep drawn steel and a heavy-duty Butyl/EPDM diaphragm for durability and leak prevention.

Product Highlights

This 86-gallon Extrol expansion tank effectively controls pressure in hydronic heating systems, featuring a 100 PSIG max pressure and 240°F max temperature.

Product Information

Standard Information

• Brand: AMTROL
• Manufacturer Part Number: SX-160V
• Country of Origin: USA

Technical Specifications

• Tank Volume: 86 Gallons
• Height: 47.25"
• Application: Heating
• Maximum Working Pressure: 100 PSIG
• Diameter: 26"
• Max Accepted Volume: 46 Gallons
• Maximum Operating Temperature: 240°F
• Factory Precharge Pressure: 12 PSIG
• Connection Size: 1-1/4 in
• Connection Type: FNPT
• Finish: Urethane Top-Coated
• Material: Steel
• Series: SX Series
