Amtrol 390602 Therm-X-Trol ST-12C-150 ST-C Diaphragm In-Line Thermal Expansion Tank

Product Description

The Amtrol Therm-X-Trol model 390602 is a diaphragm in-line thermal expansion tank designed for hot water systems. This tank is equipped to handle pressure levels up to one hundred fifty psig, ensuring reliable operation in commercial closed systems. The volume capacity of six point four gallons with a three point two gallon acceptance volume makes it suitable for various applications.

• Suitable for use in commercial hot water systems.
• Built to withstand a maximum working pressure of 150 psig.
• Features a patented turbulator design to prevent sediment build-up.

Product Highlights

This thermal expansion tank provides effective pressure control, helping to protect plumbing fixtures and improve system efficiency.

Product Information

Standard Information

• Brand: Amtrol
• Model: 390602

Technical Specifications

• ASME Certification: Yes
• Acceptance Volume: 3.2 gal
• Connection Size: 3/4 in
• Connection Type: MNPT
• Diameter: 12 in
• Height: 18 in
• Material: Drawn Steel
• Maximum Temperature: 200 deg F
• Pre-Pressure Rating: 55 psig
• Pressure Rating: 150 psig
• Series: ST-C
• Tank Volume: 6.4 gal
• Type: Diaphragm In-Line
