Amrad nsi-it-4 Insulated Tap Connector 2 Port 4-14 Awg

Product Description

The AMRAD nsi-it-4 is a 2-port, pre-insulated multi-tap connector designed for making reliable, insulation-piercing tap connections in electrical distribution and branch circuit work. Built for single-sided entry, it accepts conductor sizes from 4 AWG to 14 AWG, allowing technicians to splice or tap conductors of different gauges within a single connector body. The black insulated housing provides protection against contact and environmental exposure at the connection point. Licensed electricians use this connector in panel feeders, service extensions, and branch tap applications where a compact, no-strip solution is required.

The nsi-it-4 is suited for residential and light commercial electrical installations where multi-conductor tapping is needed without cutting the main conductor. Single-sided entry simplifies installation in tight junction boxes or conduit bodies. The connector accommodates both run and tap conductors in the 4 to 14 AWG range, making it practical for mixed-gauge tap work on lighting circuits, feeder extensions, and sub-panel connections.

Key Features

• Accepts conductors from 4 AWG to 14 AWG for mixed-gauge tap connections
• 2-port configuration supports one run conductor and one tap conductor
• Single-sided entry design for installation in confined spaces
• Pre-insulated black housing for protection at the connection point
• No-strip installation eliminates the need to remove conductor insulation before tapping

Compatibility

Designed as an OEM-style insulated tap connector for use with copper conductors ranging from 4 AWG to 14 AWG in standard residential and light commercial electrical applications.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC). De-energize and lock out the circuit before making any connections. Insert the run and tap conductors into the appropriate ports and tighten the set screws to the connector manufacturer torque guidance marked on the body or packaging. Confirm the insulated housing is fully seated and undamaged before restoring power.

Technical Specifications

• Number of Ports: 2
• Conductor Range: 4 to 14 AWG
• Entry Type: Single-sided
• Housing Color: Black
• Insulation: Pre-insulated

Standard Information

• Brand: AMRAD
• Manufacturer Part Number: nsi-it-4
