Ametek 132533 Process Pressure Gauge 0-1000 Psi 6 in

Product Description

The AMETEK 132533 is an analog process pressure gauge designed for industrial and commercial fluid system monitoring. Built around a 6-inch dial, it reads pressure from 0 to 1000 psi with an accuracy of 0.5 percent of scale. The case is thermoplastic, keeping overall weight manageable at 3 pounds, while all wetted parts are stainless steel to resist corrosion in demanding process environments. The lower-mount, 1/2-inch NPT connection makes it straightforward to install inline or at a port on tanks, pumps, compressors, and piping manifolds. Licensed tradespeople and experienced technicians working in HVAC, plumbing, water treatment, and general process applications are the primary installers of this gauge.

The AMETEK 132533 Series 1931 process gauge is suited for residential and commercial applications where a large, easy-to-read dial and reliable pressure indication are required. Typical install scenarios include pump discharge lines, compressed air systems, hydraulic circuits, and water supply manifolds. It is a dry (non-liquid-filled) gauge, making it appropriate for systems where fluid contamination of the gauge internals is not a concern. Its black dial face and analog display provide clear readings from a distance in mechanical rooms and equipment enclosures.

Key Features

• 6-inch analog dial provides high visibility in low-light or busy mechanical environments
• 0 to 1000 psi pressure range covers a wide variety of process and utility applications
• 0.5 percent of scale accuracy meets demanding process measurement requirements
• Stainless steel wetted parts resist corrosion from aggressive media
• Thermoplastic case reduces overall weight and resists many common chemicals
• 1/2-inch lower-mount NPT connection fits standard pipe thread ports
• Dry gauge construction eliminates fill-fluid contamination risk

Compatibility

Designed as an OEM-style replacement or direct-install process pressure gauge for systems with a 1/2-inch NPT lower-mount port requiring a 0 to 1000 psi analog gauge.

Installation Notes

A licensed plumber, pipefitter, or qualified HVAC technician should install this gauge in accordance with applicable codes such as the IPC or ASME B31.3 for process piping. Depressurize and isolate the system completely before removing any existing gauge or fitting the new one. Use an appropriate thread sealant rated for the media and pressure range on the NPT threads. Do not overtighten the gauge body by gripping the dial case; always apply wrench force to the hex fitting only.
