Ametek 132514 Pressure Gauge 6 in 400 Psi Lower Mount

Product Description

The AMETEK 132514 is an analog pressure gauge designed for measuring system pressure in a range of industrial and mechanical applications. It features a 6-inch dial with a 0 to 400 psi measurement range and delivers 0.5% of scale accuracy, making it suitable for applications where precise pressure readings are required. The lower-mount configuration accepts a 1/2-inch thread connection, and the case is constructed from thermoplastic for durability and corrosion resistance. This gauge is typically installed by licensed plumbers, HVAC technicians, or mechanical contractors during system commissioning, maintenance, or troubleshooting.

The AMETEK 132514 is suited for use in residential and commercial mechanical systems where monitoring line or vessel pressure is part of routine service. The 6-inch dial provides high visibility in panel-mount or pipe-mounted installations. The lower-mount thread orientation is standard in many piping configurations and makes direct in-line installation straightforward. Typical applications include HVAC systems, water supply and distribution piping, compressed air systems, and other fluid handling setups where pressure monitoring is required.

Key Features

• 0 to 400 psi pressure range for broad system compatibility
• 0.5% of scale accuracy for reliable, precise readings
• 6-inch analog dial for high-visibility pressure monitoring
• Lower-mount configuration with 1/2-inch thread connection
• Thermoplastic case construction resists corrosion in damp or chemically active environments

Compatibility

Designed as an OEM-style replacement or direct-install pressure gauge for mechanical systems requiring a 6-inch lower-mount analog gauge with a 1/2-inch threaded connection and a 0 to 400 psi range.

Installation Notes

Installation should be performed by a licensed plumber, HVAC technician, or qualified mechanical contractor in accordance with applicable local codes. Depressurize and isolate the system completely before removing or installing any pressure gauge. Use appropriate thread sealant on the 1/2-inch NPT connection to prevent leaks, and tighten to the fitting manufacturer's specifications without over-torquing the thermoplastic case. Confirm the system operating pressure falls within the 0 to 400 psi range before returning the system to service.
