American Standard 6400014 Urinal Inlet Spud 1x3/4 Inch Brass

Product Description

The AMERICAN STANDARD 6400014 is a brass urinal inlet spud designed as a repair replacement for top spud urinal fixtures. The spud connects the flush valve supply to the urinal body, providing the threaded inlet interface required for proper flush valve seating and water delivery. Sized at 1 inch inlet by 3/4 inch outlet, it is manufactured from solid brass for corrosion resistance and durability in commercial restroom environments. Licensed plumbers and facilities maintenance technicians install this component during urinal repair service when the original spud is damaged, corroded, or leaking at the inlet connection.

This inlet spud is a direct repair part for the AMERICAN STANDARD 6400.014 Stallbrook and 6501.010 Washbrook top spud urinal models. It is suited for commercial restroom applications where these fixture models are installed. The top spud configuration is common in wall-hung commercial urinals found in high-traffic facilities such as schools, offices, and public buildings. Installation is performed as part of a standard urinal flush valve service or inlet repair procedure.

Key Features

• Brass construction provides corrosion resistance for long service life in wet commercial environments
• 1 inch inlet by 3/4 inch outlet sizing matches OEM top spud urinal inlet specifications
• Designed specifically for repair application on compatible AMERICAN STANDARD top spud urinal fixtures
• Threaded fitting interfaces with standard flush valve supply connections

Compatibility

Compatible with the AMERICAN STANDARD 6400.014 Stallbrook and 6501.010 Washbrook Top Spud Urinal models as a repair inlet spud replacement.

Installation Notes

Installation is performed by a licensed plumber. Shut off the water supply to the urinal and flush the line to relieve pressure before removing the existing spud. Use appropriate pipe wrenches and thread sealant or plumber tape on threaded connections per standard plumbing practice. Work must comply with applicable local plumbing codes and IPC requirements.

Technical Specifications

• Material: Brass
• Fitting Size Inlet: 1 inch
• Fitting Size Outlet: 3/4 inch
• Product Type: Urinal Spud
• Application: Repair
• ADA Compliant: No
• WaterSense Labeled: No
• UPC: 012611147128

Standard Information

• Brand: AMERICAN STANDARD
• Manufacturer Part Number: 6400014
