American Standard 3517D.101 Cadet Pro Standard Height Round Front Bowl

Product Description

The AMERICAN STANDARD 3517D.101 Cadet PRO Round Front Toilet Bowl is engineered to enhance the features of a coordinating tank (sold separately). The bowl features a PowerWash rim that releases water to scrub the bowl. Constructed of vitreous china with an EverClean antimicrobial surface that protects against mold, mildew, and stain-causing bacteria.

• EverClean antimicrobial surface protects against bacteria
• PowerWash rim releases water to scrub the bowl
• Made of quality vitreous china

Product Highlights

The Cadet PRO Round Front Toilet Bowl features a PowerWash rim and EverClean surface. It is made of durable vitreous china.

Product Information

Standard Information

• Brand: AMERICAN STANDARD
• Manufacturer Part Number: 3517D.101

Technical Specifications

• Item Shape: Round
• Toilet Type: Bowl Only
• Flush Technology: Cadet
• Flushing Type: Not Applicable
• GPF Maximum: 1.6 gpf
• GPF Minimum: 1.28 gpf
• Toilet Trapway Diameter: 2-1/8 in
• Bidet Spray Type: Yes
• Everclean: Yes
• Item Name: Toilet Bowl
• Shape: Round Front
• Water Per Flush: 1.28 GPF
• Water Surface Area: 9 X 8 IN
• Bowl Height: 15 IN
• Rough-In: 10 IN
• Trap Way Size: 2-1/8 IN
• Mounting: Floor
• Material: Vitreous China
• Finish/Color: White
• ADA Compliant: Yes
• Bowl Width: 14 IN
• Bowl Depth: 25-5/8 IN
• Industry Standards: ASME A112.19.2-2008/CSA B45.1-08, US EPA WaterSense Specification for HETs
• MPN: 3517D101.020
• Manufacturer: American Standard
• Series: Cadet
• Height (Inches): 15"
• Length (Inches): 14"
• Finish: White
• ADA Compliance: Yes
• Flush Valve Size: 3" (diameter of the inlet for water entering bowl from tank)
• Trapway Size: 2-1/8" (diameter of the outlet for water/waste exiting the bowl)
• Flow Rate: 1.28 GPF (gallons-per-flush)
• Water Area: 9" X 8" (inner rim dimensions length X width)
• Water Depth (From Rim): 7"
• Distance Between Toilet Seat Installation Holes: 5-1/2"
• Depth: 26.25 in.
• Hinge Center to Center: 5.5 in.
• Product Weight: 50 lbs.
• Trapway: 2.125 in.
• Width: 14 in.
• Bowl Shape: Round
• Configuration: Bowl Only
• Design Features: Glazed Trapway
• Flush Type: Siphon Jet
• Installation Type: Floor Mounted
• Seat Front: Closed
• Theme: Modern
• Approved for Commercial Use: Yes
• ASME Code: A112.19.2
• Certifications: ASME, CSA
• Collection: Cadet Pro, Cadet, Everclean
• CSA Code: B45.1
