Product Description
The AMERICAN STANDARD 204AB104.020 Edgemere elongated two-piece toilet combines classic design with high-efficiency performance. This chair-height toilet features a 16-1/2" rim height and an elongated bowl. It utilizes 1.28 gpf, which is 20% less water than standard toilets. The EverClean surface inhibits the growth of bacteria.
- High efficiency, ultra-low consumption (1.28 gpf/4.8 Lpf), utilizes 20% less water
- Combination bowl and tank, less seat
- 16-1/2" (419 mm) rim height for accessible applications
Product Highlights
This Edgemere toilet is WaterSense certified, ADA compliant, and includes EZ-Install Tools for easy installation. It features a PowerWash rim and a fully glazed trapway.
Product Information
Standard Information
-
Brand: AMERICAN STANDARD
-
Manufacturer Part Number: 204AB104.020
-
Country of Origin: Mexico
Technical Specifications
-
Rough-in: 10" (254 mm)
-
Water Consumption: 1.28 gpf/4.8 Lpf
-
Rim Height: 16-1/2" (419 mm)
-
Flush Valve: 3" (76 mm)
-
Trapway: 2" (51 mm) fully glazed
-
Width: 18-7/8"
-
Height: 30-1/4"
-
Length: 28-3/16"
-
Seat Type: Less Seat
-
WaterSense: Yes
-
FinishColor: White Shades
-
Finish Name: White
-
Toilet Height: Chair Height
-
RoughIn Dimension: 10"
-
Toilet Bowl Shape: Elongated
-
TripLever Position: Left Hand Trip Lever
-
Commercial or Residential: Primarily Residential
-
Category: Toilet
-
Installation Place: Floor Mount
-
Flow Rate: 1.28 gallons-per-flush
-
Material: Vitreous China
-
Brand: American Standard
-
Bowl/Seat Shape: Elongated
-
Rough In Size: 10 inch Rough In
-
Gallons Per Flush: Single Flush: 1.28
-
10-Inch Rough-In: Yes
-
Chair-Height Comfort: Measures 17” tall, including seat, for ease of use compared to standard height, Slight variation in height may occur based on the height of the seat used
-
ADA Compliant: Meets Americans with Disabilities Act requirements for use and accessibility
-
Less Seat: Toilet seat is sold separately
-
Durable Construction: Made from quality vitreous china for strength and reliability
-
Fully Glazed 2" Trapway: Helps to prevent clogs
-
Powerful Flush: Optimal performance with a 3" flapper flush valve
-
Model Number: 204AB104.020
-
Number of pieces: 2
-
Product type: Right Height with EverClean High Efficiency
-
Finish: White
-
Bowl shape: Elongated
-
Ada compliant: Yes
-
Height Dimension: 30-5/16 IN
-
Flush rate: 1.28 GPF
-
Rough-in Dimension: 10 IN
-
Mounting: Floor Mount
-
Eco friendly: WaterSense
-
Flush type: Gravity
-
Trip lever: Left Hand
-
Toilet seat: Less Seat
-
Length Dimension: 28-3/16 IN
-
Width Dimension: 18-7/8 IN
-
Bowl height: 16-1/2 IN
-
Includes: EZ-Install tools and color-matched Bolt Caps
-
Style: Modern
-
Color family: White
-
Collection: Edgemere
-
Item Shape: Bowl Shape: Elongated
-
Toilet Seat Front Type: Closed
-
Toilet Type: Two Piece
-
Flush Valve Size: 3 in
-
Flush Technology: Gravity Fed
-
Flushing Type: Single Flush
-
GPF Maximum: 1.28 gpf
-
Tank Included: Yes
-
Insulated Toilet Tank: No
-
Toilet Seat Included: No
-
Toilet Trapway Diameter: 2 in
-
Everclean: Yes
-
No. of Flush Valves: 1
-
Overall Height: 30-5/16" (bottom of the base to the highest point on the toilet)
-
Overall Depth: 28-3/16" (furthest point back to front of toilet)
-
Overall Width: 18-7/8" (furthest point left to furthest point on the right)
-
Bowl Height Dimension: 16-1/2" (floor to the top of the bowl)
-
Trapway (Discharge Passage) Size: 2"
-
Configuration: Two Piece
-
Design Features: Glazed Trapway, Chair Height
-
Electronic: No
-
Flush Type: Siphon Jet
-
Installation Type: Floor Mounted
-
Theme: Modern
-
Trip Lever Placement: Left
-
Water Efficient: Yes
-
ADA: Yes
-
ASME Code: A112.19.2
-
Certifications: ASME, CSA
-
CSA Code: B45.1
-
WaterSense Certified: Yes
-
Gallons Per Flush Dimension: 1.28
-
Depth Dimension: 28.1875 in.
-
Product Family: EDGEMERE
-
Residential Commercial: Residential
-
Product Line Name: CHINAWARE
-
Color: White
-
Luxury/Non Luxury: Luxury
-
Proper Shipping Name: Sanitareware
-
Watersense/Water Efficient: WS
-
CEC(CA Energy Comm: Yes
-
GPF: 1.28 GPF
