American Granby ippg602-4lnl 2 Inch Plastic Pressure Gauge 0-60 Psi Bottom Mount Mip Connection

Product Description

The American Granby IPPG602-4LNL is a 2 inch plastic pressure gauge designed for pool service applications and general fluid system monitoring. It features a bottom mount MIP connection measuring 0.25 inches, which allows for straightforward inline installation on pumps, filters, and plumbing lines. The gauge reads pressure from 0 to 60 PSI, making it well suited for residential and light commercial pool systems where monitoring filter pressure and pump output is a routine part of system maintenance. Pool service technicians rely on pressure gauges like this one to identify clogged filters, verify pump performance, and confirm that a system is operating within its normal pressure range. A reading that climbs above the normal baseline typically signals a dirty filter cartridge or a DE filter in need of backwashing, while a lower than expected reading can point to a flow restriction on the suction side or a failing pump impeller. Having a reliable, easy to read gauge installed at the filter head gives technicians an immediate snapshot of system health at any service visit. The plastic construction of the IPPG602-4LNL makes it resistant to the corrosive effects of pool chemicals, including chlorine and salt water environments. Plastic body gauges are a preferred choice in pool service because they hold up better than brass or steel alternatives when exposed to chemically treated water over extended periods. The 2 inch dial face provides a clear, legible display that is easy to read in outdoor lighting conditions. The standard bottom mount MIP thread connection is compatible with most pool filter tanks and pump manifolds, allowing for quick replacement of a worn or damaged gauge without specialized fittings. This gauge is a common replacement part for pool equipment across a wide range of filter brands and configurations.

• 2 inch dial face with 0 to 60 PSI pressure range for pool and fluid system monitoring
• 0.25 inch bottom mount MIP connection for easy installation on filters and pump systems
• Plastic body construction resists corrosion from pool chemicals, chlorine, and salt water

Product Highlights

The American Granby IPPG602-4LNL is a durable plastic pressure gauge built for pool service use, offering a clear 0 to 60 PSI range and a standard 0.25 inch bottom mount MIP connection that fits most pool filter and pump installations.

Product Information

Standard Information

• Brand: AMERICAN GRANBY
• Manufacturer Part Number: ippg602-4lnl

Technical Specifications

• Dial Size: 2 inches
• Pressure Range: 0 to 60 PSI
• Connection Size: 0.25 inches
• Connection Type: Bottom Mount MIP
• Body Material: Plastic
• Department: Pool Service
