American Granby ILPG20025-4L Liquid-Filled Pressure Gauge 0-200 PSI (2.5-inch)

Product Description

The American Granby ILPG20025-4L is a liquid-filled pressure gauge with a 2.5-inch dial and a 0-200 PSI range for monitoring air and water systems in pump, HVAC, irrigation, and plumbing applications. It has a 1/4-inch male lower mount, a 304 stainless steel case with crimped ring, a polycarbonate/acrylic lens, a phosphor bronze bourdon tube, glycerine fill to damp vibration, and typical accuracy of �3% of full scale.

• 2.5-inch dial, 0-200 PSI range, typical accuracy �3% of full scale
• 1/4-inch MIP lower mount; 304 stainless steel case with crimped stainless crimp ring; polycarbonate/acrylic lens
• Glycerine-filled with phosphor bronze bourdon tube to damp vibration and pulsation; suitable for air and water systems

Product Highlights

2.5-inch liquid-filled pressure gauge, 0-200 PSI, 1/4-inch lower MIP connection, stainless steel case, glycerine fill

Product Information

Standard Information

• Brand: AMERICAN GRANBY
• Manufacturer Part Number: ILPG20025-4L

Technical Specifications

• Brand: American Granby
• MPN: ILPG20025-4L
• SKU: 3216
• Series: ILPG Series
• Dial Size: 2.5 inch (63 mm)
• Pressure Range: 0-200 PSI
• Connection: 1/4-inch MIP (male), lower mount
• Case Material: 304 stainless steel with crimped ring
• Crimp Ring: Stainless steel
• Lens Material: Polycarbonate / acrylic
• Fill: Glycerine (liquid-filled)
• Bourdon Tube Material: Phosphor bronze
• Accuracy: �3% of full scale (typical)
• Suitable Media: Air and water (consult manufacturer for other media)
• Applications: Pump systems, HVAC, irrigation, plumbing
• Weight: 0.52 lb
• Dimensions: 4 in x 4 in x 4 in
