American Granby EILVG302-4LSSNL LIQ GAUGE VAC 30HG 2D 1/4LM NL

Product Description

The American Granby EILVG302-4LSSNL is a vacuum gauge with a two-inch dial and a measuring range from zero to thirty inches of mercury. It features a one-quarter inch MNPT lower mount and is designed for liquid filling using glycerine. This gauge has a stainless steel case and meets industry standards for accuracy and durability.

• Accuracy of +/-3-2-3 %
• Suitable for high vibration and corrosive environments
• Must be used with air or water only

Product Highlights

This vacuum gauge is built to withstand tough conditions, making it ideal for various plumbing applications.

Product Information

Standard Information

• Manufacturer: American Granby Inc
• Model Number: EILVG302-4LSSNL

Technical Specifications

• Dial Size: 2 inches
• Case Material: 304 Stainless Steel
• Connection Type: 1/4 inch MNPT Lower Mount
• Measuring Range: 0 to 30 inches of mercury
• Liquid Filled: Glycerine
• Lens Material: Acrylic
• Ring Material: Stainless Steel
• Socket Material: No Lead Brass/Stainless Steel
• Tube Material: Phosphor Bronze
