American Granby 961225 Double Wall Oil Tank 190 Gallon

Product Description

The AMERICAN GRANBY 961225 is a 190-gallon double wall heating oil storage tank designed for residential and light commercial fuel oil systems. The primary tank is constructed from blow-molded high-density polyethylene (HDPE) with fluorination treatment to control oil odors. The secondary containment shell is fabricated from tightly welded galvanized steel, providing a fully integrated spill containment structure. Connection fittings are cast aluminum for torque resistance and peripheral sealing. A built-in visual leak indicator allows ongoing monitoring of primary tank integrity. This tank ships with accessories included and carries a 30-year limited warranty against manufacturing defects and internal corrosion.

The 961225 is suited for indoor and outdoor fuel oil storage installations in residential heating applications. Overall dimensions are 44 inches length by 28 inches width by 48 inches height, making it compatible with standard basement, garage, and utility room placements. The tank comes ready for connection with burner oil supply openings sized at 3/8 inch and 1/2 inch. Licensed oil burner technicians and fuel oil service professionals are the primary installers for this unit.

Key Features

• 190-gallon capacity with HDPE primary tank and galvanized steel secondary containment
• Fluorination-treated interior resists oil odors, exclusive to Granby 2-in-1 tank design
• Visual leak indicator monitors primary tank integrity without tools
• Cast aluminum connection fittings provide high torque resistance and tight peripheral sealing
• Rated for both indoor and outdoor installation
• 30-year limited warranty against manufacturing defects and internal corrosion

Compatibility

Designed as an OEM-style double wall oil tank for residential and light commercial fuel oil heating systems with standard 3/8-inch and 1/2-inch burner supply connections.

Installation Notes

Installation must be performed by a licensed oil burner technician or qualified fuel oil service professional in accordance with applicable local, state, and NFPA 31 codes governing fuel oil storage and piping. Shut off all fuel supply lines and confirm tank area is free of ignition sources before beginning installation. Do not overtighten cast aluminum fittings; follow the fitting manufacturer torque guidance. Verify secondary containment clearances and ventilation requirements with the authority having jurisdiction before placing the tank in service.

Technical Specifications

• Capacity: 190 gallons
• Overall Dimensions: 44 inches length x 28 inches width x 48 inches height
• Burner Oil Supply Opening Size: 3/8 inch and 1/2 inch
• Primary Tank Material: Blow-molded high-density polyethylene (HDPE), fluorination treated
• Secondary Containment Material: Welded galvanized steel
• Fitting Material: Cast aluminum
• Application: Indoor and outdoor
• Included Accessories: 2-inch threaded galvanized steel fill pipe adaptor, low pressure vent and overfill protection alarm, oil level gauge, oil burner supply duplex bushing with tube adapter
• Warranty: 30-year limited

Standard Information

• Brand: AMERICAN GRANBY
• Manufacturer Part Number: 961225
