Amana DHP094J35BA Distinctions 9k Heat Pump PTAC 265V 20 amp

Product Description

The Amana DHP094J35BA Distinctions PTAC unit provides a reliable, high-quality option for premium comfort. This unit features R-32 refrigerant, dual fan motors for quiet operation, and a LCDI power cord. It delivers 9,000 BTU/h cooling and 8,000 BTU/h heating capacity, with a 3.5 kW electric heater.

• R-32 Refrigerant: Offers 68% lower Global Warming Potential (GWP) compared to R-410A.
• Dual Fan Motors: Allows precise independent fan speed while providing quiet operation.
• Automatic Emergency Heat: Switches to electric resistance heat if the heat pump fails.

Product Highlights

The Amana DHP094J35BA PTAC unit ensures energy efficiency and easy maintenance with washable filters and a condensate dispersion system.

Product Information

Standard Information

• Brand: AMANA
• Manufacturer Part Number: DHP094J35BA

Technical Specifications

• Model: DHP094J35BA
• COOLING CAPACITY (BTU/h): 9,000
• Heating CAPACITY (BTU/h): 8,000
• ELECTRIC HEAT CAPACITY: 3.5 kW
• EER: 11.3
• VOLTAGE: 265V
• Capacity (BTU/h): 9,000
• Amps: 2.9
• Watts: 620
• CFM (cool/wet coil) High: 389
• CFM (cool/wet coil) Low: 328
• CFM (dry) High: 389
• CFM (dry) Low: 328
• Vent door CFM: 61.1 / 57.6 / 50.6
• Dehumidification (pints/hr.): 1.16
• Heater size (kW): 3.5
• Heating capacity (BTU/h): 10,900
• COP: 3.3
• CFM (Dry) High Speed: 389
• W x H x D (inches): 42 x 16 x 21
• Type of Through-the-Wall: 42" PTAC
• Sleeve Required for Install: Yes
• Fits Sleeve Size (in.): 42
• Refrigerant Type: R32
• Compressor: Standard
• Energy Star: No
• CFMs: 328 / 389 (L / H)
• Includes Heat Mode: Yes
• Heat Type: Heat Pump with Back-Up Electric
• Cooling BTUs (@265V): 9000
• Cooling Amps (@265V): 3.9
• Cooling Watts (@265V): 770
• Electric Heat Strip Size (kW - @265V): 3.5
• Electric Heating BTUs (@265V): 10900
• Electric Heating Amps (@265V): 13.2
• Electric Heating Watts (@265V): 3500
• Heat Pump BTUs (@265V): 8000
• Heat Pump Heating Amps (@265V): 2.9
• Heat Pump Heating Watts (@265V): 620
• Vent Location: Front Top
• Make-Up Air: No
• Energy Saver Mode: Yes
• Control Type: Wall Thermostat Required
• Connectivity: Not WiFi Compatible
• 24 Hour ON/OFF Timer: No
• Remote Control: No
• Fresh Air Intake: Yes
• Sleep Mode: No
• Weight (lbs.): 99.21
• Certifications: ETL / AHRI
• Plug Face (NEMA): 7-20P
• Circuit Breaker Size (Amps): 20
• Cord Length: NA
