Amana DHP073J25BA Distinctions 7k Heat Pump PTAC 208/230V 15 amp

Product Description

The Amana DHP073J25BA is a distinctions PTAC unit that provides 7,000 BTUs of cooling and heat for year-round comfort. It features R-32 refrigerant with a lower Global Warming Potential (GWP) compared to R-410A. This unit operates on 208/230V and includes a LCDI power cord.

• Dual fan motors allow precise independent fan speed while providing quiet operation.
• 3-speed fan provides precise comfort control.
• Easy pull-out filters are washable and easy to maintain.

Product Highlights

This Amana PTAC unit offers energy efficiencies with an EER up to 13.1 and COPs up to 3.4. It has a condensate dispersion system and automatic emergency heat.

Product Information

Standard Information

• Brand: AMANA
• Manufacturer Part Number: DHP073J25BA

Technical Specifications

• Model: DHP073J25BA
• COOLING CAPACITY (BTU/h): 7,200/7,100
• Heating CAPACITY (BTU/h): 6,200/6,000
• ELECTRIC HEAT CAPACITY: 2.5/2.1 kW
• EER: 13.1
• VOLTAGE: 230/208V
• Capacity (BTU/h): 7,200 / 7,100
• Amps: 3.0 / 3.3
• Watts: 550 / 540
• CFM (cool/wet coil) High: 355
• CFM (cool/wet coil) Low: 295
• CFM (dry) High: 355
• CFM (dry) Low: 295
• Vent door CFM: 61.1 / 57.6 / 50.6
• Dehumidification (pints/hr.): 0.70
• Heater size (kW): 2.5
• Heating capacity (BTU/h): 7,800 / 6,300
• Watts (Electric Heat): 2,580 / 2,150
• Amps (Electric Heat): 11.3 / 10.3
• Capacity (BTU/h) Reverse Cycle: 6,200 / 6,000
• Amps (Reverse Cycle): 2.6 / 2.7
• Watts (Reverse Cycle): 480 / 460
• COP: 3.60
• CFM (Dry) High Speed: 355
• W x H x D (inches): 42 x 16 x 21
• Net weight (lbs.): 101.41
• Type of Through-the-Wall: 42" PTAC
• Sleeve Required for Install: Yes
• Fits Sleeve Size (in.): 42
• Refrigerant Type: R32
• Compressor: Standard
• Energy Star: No
• CFMs: 295 / 355 (L / H)
• Includes Heat Mode: Yes
• Heat Type: Heat Pump with Back-Up Electric
• Cooling BTUs (@208V): 7100
• EER (@208V): 13.1
• Cooling Amps (@208V): 3.3
• Cooling Watts (@208V): 540
• Electric Heat Strip Size (kW - @208V): 2.1
• Electric Heating BTUs (@208V): 6300
• Electric Heating Amps (@208V): 10.3
• Electric Heating Watts (@208V): 2150
• Heat Pump BTUs (@208V): 6000
• COP (@208V): 3.6
• Heat Pump Heating Amps (@208V): 2.7
• Heat Pump Heating Watts (@208V): 460
• Cooling BTUs (@230V): 7100
• Cooling Amps (@230V): 3.0
• Cooling Watts (@230V): 550
• Electric Heat Strip Size (kW - @230V): 2.5
• Electric Heating BTUs (@230V): 7800
• Electric Heating Amps (@230V): 11.3
• Electric Heating Watts (@230V): 2580
• Heat Pump BTUs (@230V): 6200
• Heat Pump Heating Amps (@230V): 2.6
• Heat Pump Heating Watts (@230V): 480
• Vent Location: Front Top
• Make-Up Air: No
• Energy Saver Mode: Yes
• Fan Speeds: 3
• Control Type: Electronic/Digital
• Connectivity: Not WiFi Compatible
• 24 Hour ON/OFF Timer: No
• Remote Control: No
• Fresh Air Intake: Yes
• Sleep Mode: No
• Plug Face (NEMA): 6-15P
• Circuit Breaker Size (Amps): 15
• Cord Length: NA
• Dimensions - (Shipping Unit Width): 42 in
• Dimensions - (Shipping Unit Height): 16 in
• Dimensions - (Shipping Unit Depth): 21 in
• Weight - (Shipping Unit): 101.41 lb
