Amana DCP073J35BA Distinctions 7k Electric Heat PTAC 208/230V 20 amp

Product Description

The Amana DCP073J35BA PTAC unit provides 7,300 BTU's of cooling and covers rooms of up to 240 sq. ft. It features dual fan motors, a 3-speed fan, R-32 Refrigerant, LCDI Power Cord, and is Wired Thermostat compatible. It has high energy efficiencies and may qualify for rebates offered by electrical power companies.

• R-32 Refrigerant: 68% lower Global Warming Potential (GWP) and can reduce direct emissions from refrigerant by up to 73.6% as compared to R-410A
• Dual Fan Motors: Allows precise independent fan speed while providing quiet operation.
• LCDI Power Cord Included: No need to match power cord type to unit size.

Product Highlights

The Amana DCP073J35BA is a reliable 7,000 BTU class PTAC with electric resistance heating, digital controls, and multiple fan speeds. It uses R-32 refrigerant and is designed for through-the-wall installation.

Product Information

Standard Information

• Brand: AMANA
• Manufacturer Part Number: DCP073J35BA

Technical Specifications

• Model: DCP073J35BA
• COOLING CAPACITY (BTU/h): 7,300 / 7,200
• ELECTRIC HEAT CAPACITY: 3.5 / 2.9 kW
• EER: 13.1
• VOLTAGE: 208/230V
• Capacity (BTU/h): 7,300 / 7,200
• Amps: 15.3 / 13.7
• Watts: 3,500 / 2,897
• CFM (cool/wet coil) High: 346
• CFM (cool/wet coil) Low: 285
• CFM (dry) High: 346
• CFM (dry) Low: 285
• Vent door CFM: 61.1 / 57.6 / 50.6
• Dehumidification (pints/hr.): 0.63
• Heater size (kW): 3.5
• Heating capacity (BTU/h): 10,900 / 8,900
• Type of Through-the-Wall: 42" PTAC
• Sleeve Required for Install: Yes
• Fits Sleeve Size (in.): 42
• Refrigerant Type: R-32
• Compressor: Standard
• Energy Star: No
• CFMs: 285 / 346 (L / H)
• Includes Heat Mode: Yes
• Heat Type: Electric Resistance Only
• Cooling BTUs (@208V): 7200
• Cooling Amps (@208V): 3.4
• Cooling Watts (@208V): 550
• Electric Heat Strip Size (kW - @208V): 2.9
• Electric Heating BTUs (@208V): 8900
• Electric Heating Amps (@208V): 13.7
• Electric Heating Watts (@208V): 2897
• Cooling BTUs (@230V): 7300
• Cooling Amps (@230V): 3.1
• Cooling Watts (@230V): 560
• Electric Heat Strip Size (kW - @230V): 3.5
• Electric Heating BTUs (@230V): 10900
• Electric Heating Amps (@230V): 15.3
• Electric Heating Watts (@230V): 3500
• Vent Location: Front Top
• Make-Up Air: No
• Energy Saver Mode: Yes
• Fan Speeds: 3
• Control Type: Digital
• Connectivity: Not WiFi Compatible
• 24 Hour ON/OFF Timer: No
• Remote Control: No
• Fresh Air Intake: Yes
• Sleep Mode: No
• Certifications: ETL / AHRI
• Voltage: 208-230V
• Plug Face (NEMA): 6-20P
• Circuit Breaker Size (Amps): 20
• Cord Length: NA
• Brand: Amana
• Model #: DCP073J35BA
• Voltage Requirements: 208V/230V
• Cooling Capacity: Approx. 7,000 BTU
• Heating Type: Electric Resistance Heat
• Amperage: 20 Amp
• Indoor Airflow: Variable fan operation
• Wall Sleeve Size: Standard PTAC (42 x 16 )
