Amana ar9s961205dn 96 Afue Gas Furnace 120000 Btu/h

Product Description

The Amana ar9s961205dn is a 96 AFUE single-stage, multi-speed gas furnace designed for upflow and horizontal ducted installations. It delivers 120,000 BTU/h high-fire input capacity with a rated output of 115,320 BTU/h, achieving 96 percent efficiency — qualifying for ENERGY STAR certification. The unit runs on a 115-volt, single-phase, 60 Hz AC supply with a minimum circuit amperage of 16.7 amps and a maximum overcurrent protection of 25 amps. The ECM blower motor provides multi-speed airflow up to 2,047 CFM at high fire, helping maintain consistent temperature distribution across the duct system. Licensed HVAC technicians install and commission this furnace in residential and light commercial applications.

The ar9s961205dn belongs to the AR9S96 series and is built for ducted indoor applications in upflow or horizontal configurations. With a nominal cooling coil match of 5 tons (60,000 BTU/h), it pairs with compatible split-system cooling equipment in whole-home HVAC systems. The temperature rise range at high fire is 35 to 65 degrees F, giving technicians a defined operating band for static pressure and airflow balancing during commissioning. It is produced in the United States and carries ANSI certification. This unit is suited for residential new construction and retrofit projects where high-efficiency single-stage heating is required.

Key Features

• 96 AFUE efficiency rating — ENERGY STAR certified
• 120,000 BTU/h high-fire input with 115,320 BTU/h output capacity
• Multi-speed ECM blower with up to 2,047 CFM high-fire airflow
• Single-stage gas valve for straightforward control wiring
• Upflow and horizontal installation configurations supported
• Non-NOx burner design; ANSI certified; produced in the United States

Compatibility

The ar9s961205dn is part of the Amana AR9S96 series and is designed to match with 5-ton (60,000 BTU/h nominal) split-system cooling equipment in ducted residential and light commercial HVAC systems. No additional specific model compatibility data was provided in the product input.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with the International Fuel Gas Code (IFGC), local mechanical codes, and the manufacturer installation instructions. Shut off all electrical power and close the gas supply valve before beginning any service or installation work. Verify duct static pressure and airflow balance against the temperature rise range of 35 to 65 degrees F at high fire before finalizing startup. The unit requires a properly sized flue venting system; consult the installation manual for approved venting configurations and materials.

Technical Specifications

• AFUE: 96%
• High-Fire Input Capacity: 120,000 BTU/h
• High-Fire Output Capacity: 115,320 BTU/h
• Nominal Cooling Capacity: 60,000 BTU/h (5 Ton)
• Power Voltage: 115 volts
• Power Phase: Single Phase
• Power Frequency: 60 Hz
• Minimum Circuit Amps: 16.7 amps
• Max Overcurrent Protection: 25 amps
• Airflow Rate (High Fire Heating): 2,047 ft3/min
• Temperature Rise Range (High Fire): 35-65 degrees F
• Gas Valve Type: Single Stage
• Motor Speed Type: Multi-Speed ECM
• Installation Configuration: Upflow/Horizontal
• Unit Width: 24.5 inches
• Unit Height: 34.5 inches
• Unit Depth: 28.875 inches
• Blower Diameter: 11 inches
• Blower Width: 11 inches
• Unit Weight: 154 pounds
• Burner Type: Non-NOx
• Current Type: AC
• Communication Feature: No
• ENERGY STAR Certified: Yes
• ANSI Certified: Yes
• Country of Origin: United States
• Standard Parts Warranty (Residential): All Parts 5 Years; Heat Exchanger 20 Years
• Registered Parts Warranty (Residential): All Parts 10 Years; Heat Exchanger 20 Years
• Standard Parts Warranty (Commercial): All Parts 5 Years; Heat Exchanger 20 Years
• Registered Parts Warranty (Commercial): All Parts 5 Years; Heat Exchanger 20 Years

Standard Information

• Brand: Amana
• Manufacturer Part Number: ar9s961205dn
