Allied Commercial AC373 Allied Commercial KGB048S4DM-Y K-Series Gas/Electric Packaged Rooftop Unit 4 ton 108000 Btu/hr Heating

Product Description

The Allied Commercial AC373 is a gas/electric packaged rooftop unit with a nominal capacity of four tons, providing heating of 108,000 Btu per hour. It operates at an efficiency of 81% AFUE and uses 208/230 volts of power. The unit delivers a cooling capacity of 48,000 Btu per hour and features a high EER rating of 11.5.

• Integrated VAV supply fan technology for variable air volume.
• Efficient Eco-Last coil system that reduces refrigerant usage.
• Easy access for diagnostics and servicing.

Product Highlights

Designed for efficiency and ease of maintenance, the AC373 is ideal for commercial applications needing reliable heating and cooling solutions.

Product Information

Standard Information

• Brand: Allied Commercial
• Part Number: L9438

Technical Specifications

• AFUE Rating: 81%
• Air Flow Type: Downflow/Horizontal
• Coil Type: Condenser
• Cooling Capacity: 48,000 Btu/hr
• Dimensions: 85-1/4 in W x 47 in D x 38-7/8 in H
• Drive Type: Direct
• Efficiency Rating EER: 11.5
• Efficiency Rating SEER: 14
• Flow Rate: 1,600 cfm
• Frequency Rating: 60 Hz
• Heat Input: 2-Stage Medium Gas
• Heating Capacity: 108,000 Btu/hr
• Material: Heavy Gauge Steel Panel
• Mfg Standards/Approvals: AHRI 340/360-2007 | ASHRAE 90.1-2010 | CSA Certified | ETL Listed | UL Listed
• Motor HP: 1/4 hp Condenser and 1/2 hp Blower hp
• Motor RPM: 825 rpm
• Nominal Capacity: 4 ton
• Number of Phases: 3 ph
• Number of Speeds: 1
• Power Rating: 4.1 kW
• Refrigerant Type: R-410A
• Series: K-Series KGB
• Voltage Rating: 208/230 V
• Warranty: 10 Years Limited Heat Exchanger, 5 Years Limited Compressor
