Allied Air A96DS2V110C20S Gas Furnace 96% 110K Btu

Product Description

The ALLIED AIR A96DS2V110C20S is a high-efficiency, two-stage variable speed downflow gas furnace rated at 96% AFUE with an input of 110,000 BTU/h and an output of 106,000 BTU/h. It uses an ECM variable speed motor and communicating controls, making it compatible with modern zoning and thermostat systems. Designed for residential installations, the furnace delivers up to 2,015 SCFM and is sized for 5-ton cooling applications. Licensed HVAC technicians install this unit in downflow configurations where supply air discharges downward through the base of the cabinet.

The A96DS2V110C20S is suited for residential forced-air heating systems in downflow applications, such as installations in closets or platforms where ductwork runs beneath the unit. It supports R-410A and R-22 refrigerant systems and is compatible with heat pump and air conditioning coil configurations. The communicating design allows integration with variable-speed air handlers and smart thermostats in multi-stage comfort systems. The unit carries an Energy Star rating, qualifying it for applicable rebate programs in many regions.

Key Features

• 96% AFUE two-stage operation reduces fuel consumption at partial load conditions
• ECM variable speed motor provides quiet, efficient airflow at 1,519 to 2,015 SCFM
• Communicating controls support integration with zoning systems and smart thermostats
• Downflow configuration with 19.875 x 19.5 inch supply duct opening for direct underfloor duct connections
• R-410A and R-22 compatible for pairing with existing or new refrigerant coil systems
• Energy Star certified and manufactured in the USA
• High-temperature engineered polymer drain pan with Microban antimicrobial additive

Compatibility

Compatible with R-410A and R-22 air conditioning and heat pump coil systems. Designed as a downflow gas furnace for residential forced-air systems requiring a 5-ton nominal cooling match. Piston and TXV installation options are supported via externally accessible coil body design.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with local mechanical codes and the manufacturer instructions. Shut off gas supply and disconnect electrical power before servicing or connecting any components. The downflow orientation requires a proper platform or subbase to support the unit above the supply duct opening. Follow all applicable IFGC requirements for gas line sizing, venting, and combustion air provisions.

Technical Specifications

• AFUE: 96%
• Input Capacity: 110,000 BTU/h
• Output Capacity: 106,000 BTU/h
• Nominal Cooling Size: 5 tons
• Staging: Two-Stage
• Motor Type: ECM Variable Speed
• Airflow (Nominal CFM): 2,015 SCFM (high) / 1,519 SCFM (low)
• Configuration: Downflow
• Fuel Type: Natural Gas
• Voltage: 120 volts AC, 60 Hz, 1-Phase
• Width: 21 inches
• Depth: 28.5 inches
• Height: 33 inches
• Supply Duct Width: 19.875 inches
• Supply Duct Depth: 19.5 inches
• Weight: 176 pounds
• Energy Star: Yes
• Country of Origin: USA

Standard Information

• Brand: ALLIED AIR
• Manufacturer Part Number: A96DS2V110C20S
