Allied Air 25f93 Ac Condenser 2 Ton 208-230V R454B

Product Description

The ALLIED AIR 25f93 is a single-stage split-system air conditioner condenser designed for residential cooling applications. Rated at 2 tons nominal capacity, it operates on 208/230 volts, single phase, 60 Hz power and uses R-454B refrigerant, a lower global warming potential alternative to R-410A. The unit is marketed under the Ducane Omniguard product line and carries an efficiency rating of up to 16 SEER2. Licensed HVAC technicians install and commission this condenser as part of a matched split system, pairing it with a compatible evaporator coil and air handler or furnace.

This condenser is intended for residential single-phase split-system installations where R-454B refrigerant service is required. The Omniguard platform targets standard residential forced-air cooling applications. As an outdoor condensing unit, it connects to an indoor evaporator coil via refrigerant line sets and low-voltage control wiring. The 2-ton nominal capacity suits smaller residential structures or zone applications where moderate cooling loads are the norm.

Key Features

• 2 ton nominal cooling capacity for residential split systems
• Up to 16 SEER2 efficiency rating under current DOE testing standards
• R-454B refrigerant — lower GWP alternative to R-410A
• Single-stage cooling operation for straightforward system integration
• 208/230 volt, single phase, 60 Hz electrical compatibility
• Ducane Omniguard product line — designed for matched coil split-system configurations

Compatibility

Designed for use as the outdoor condensing unit in a matched R-454B split-system configuration. The raw product data references the Ducane Omniguard coil split system, model reference 7AC13F24P. Verify indoor coil and air handler compatibility with the manufacturer before installation, as R-454B systems require matched, rated components.

Installation Notes

Installation must be performed by an EPA Section 608 certified HVAC technician, as R-454B is a mildly flammable (A2L) refrigerant requiring adherence to updated handling and installation safety procedures. Power down and lock out the disconnect before making any electrical connections. Follow all local mechanical and electrical codes, including NEC requirements for outdoor disconnect placement and conductor sizing. Do not mix refrigerant types or attempt to retrofit this unit with refrigerants other than R-454B.

Technical Specifications

• Cooling Capacity: 2 ton nominal
• Efficiency Rating: Up to 16 SEER2
• Voltage: 208/230 volts
• Phase: 1 phase
• Frequency: 60 Hz
• Refrigerant: R-454B
• Stages: Single stage
• System Type: Split system condenser

Standard Information

• Brand: ALLIED AIR
• Manufacturer Part Number: 25f93
