Allied Air 24Y07 97G2UH135DV20 Gas Furnace 135000 BTU 5 Ton Upflow/Horizontal

Product Description

Allied Air 24Y07 is a two-stage gas furnace (model 97G2UH135DV20) with a variable-speed blower and nominal 135,000 BTU/hr input designed for upflow or horizontal installation. The unit provides 97% AFUE efficiency, ECM variable speed blower with soft start/stop, and a stainless steel secondary heat exchanger. It includes System Sentry control with fault memory, hot surface silicon nitride ignition, and left or right gas/electric entry for flexible installation.

• Two-stage gas valve with variable-speed ECM blower and induced-draft motor for staged heating and airflow control
• High-efficiency design with 97% AFUE, aluminized primary and AL29-4C stainless steel secondary heat exchangers
• System Sentry control with fault memory, hot surface silicon nitride ignition, removable slide-out blower, and upflow/horizontal conversion

Product Highlights

Two-stage 97% AFUE gas furnace, 135,000 BTU input, variable-speed blower, upflow/horizontal configuration.

Product Information

Standard Information

• Brand: ALLIED AIR
• Manufacturer Part Number: 24Y07

Technical Specifications

• Manufacturer: Allied Air Enterprises
• Brand: Allied Air
• MPN: 24Y07
• Model: 97G2UH135DV20
• Input Capacity (BTU/hr): 135,000
• Output Capacity (BTU/hr): 127,000
• AFUE Rating: 97%
• Configuration: Upflow/Horizontal
• Number of Stages: 2
• Motor Type: Variable speed ECM blower; induced-draft motor
• Airflow (CFM): 2000 CFM
• Voltage: 120 V AC
• Dimensions (W x D x H): 24.5 in x 28.5 in x 33 in
• Weight: 178 lbs
• Gas Inlet Size: 1/2 in
• Connection Size: 1/2 in
• Fuse Size: 20 A
• Heat Exchanger Material: Aluminized steel primary; AL29-4C stainless steel secondary
• Ignition Type: Hot surface silicon nitride ignitor
• Control: System Sentry control with fault memory
• UPC: 662551588958
• Series: 97G2V
