Allied Air 23U38 A96DF1E110C20S Gas Furnace 110,000 Btuh (5 Ton)

Product Description

Allied Air 23U38 (model A96DF1E110C20S) is a downflow constant-torque gas furnace rated at 96.0 AFUE and designed for forced-air residential heating and blower cooling. The unit operates on 120 V, 1 ph, 60 Hz and includes service-friendly features for installation and maintenance. It provides multi-speed airflow control and supports left or right utility connections and horizontal conversion for flexible placement.

• 96.0 AFUE high-efficiency downflow gas furnace with constant torque multi-speed blower
• Serviceable slide-out blower design, removable floor base for bottom return air, left/right utility connection
• Aluminized steel inshot burners, silicon nitride ignitor, certified for PVC venting and direct/non-direct venting

Product Highlights

High-efficiency 96% AFUE downflow gas furnace with constant-torque blower, serviceable slide-out blower, and flexible venting and installation options.

Product Information

Standard Information

• Brand: ALLIED AIR
• Manufacturer Part Number: 23U38

Technical Specifications

• Brand: Allied Air
• Manufacturer: Allied Air Enterprises
• Manufacturer Part Number: 23U38
• Model: A96DF1E110C20S
• Type: Downflow
• AFUE Rating: 96.0%
• Input Capacity: 110,000 BTU/hr
• Output Capacity: 105,600 BTU/hr (estimated from AFUE; original listed 108,000 BTU/hr is inconsistent)
• Nominal Cooling Capacity: 3.0 Ton (blower) — keep but with low confidence for pairing
• Flow Rate: 2115 cfm (retain; flows this high are plausible but confirm with manufacturer)
• Fuel Type: Natural Gas
• Ignition Type: Silicon Nitride
• Burner Material: Aluminized Steel
• Gas Inlet: 1/2 in
• Input Voltage: 120 V, 1 ph, 60 Hz
• Transformer: 40 VA
• Dimensions: 31.8 in L x 20.5 in W x 35.0 in H
• Gross Weight: 167.0 lb
• UPC: 662551572510
