Allied Air 16G54 4 Ton Heat Pump Condenser

Product Description

The Allied Air 16G54 is a 4-ton heat pump condenser suitable for both residential and commercial HVAC systems. It is part of the 4HP15L series and uses R-410A refrigerant. This unit operates on a power source of 208/230 VAC, single-phase, 60 Hz.

• Nominal capacity of 4 tons
• High-efficiency scroll compressor
• Designed for heating and cooling

Product Highlights

The Allied Air 16G54 provides reliable performance and efficiency, making it ideal for various HVAC applications.

Product Information

Standard Information

• Brand: Allied Air
• MPN: 16G54

Technical Specifications

• Series: 4HP15L
• Nominal Capacity: 4 ton
• Heating Capacity: 46000 Btu/hr
• Power Source: 208/230 VAC, 1 ph, 60 Hz
• EER Rating: 12
• HSPF Rating: 8.2
• Compressor Type: High-Efficiency Scroll
• Refrigerant Type: R-410A
• Suction Line Size: 7/8 in
• Discharge Line Size: 3/8 in
• Fuse Size: 45 A
• Temperature Rating: 125 deg F
• Sound Level: 80 dBA
• Dimensions: 32-1/4 in W x 32-1/4 in D x 37-1/4 in H
• Efficiency: High Efficiency
• SEER Rating: 14
• COP Rating: 3.3
• Cooling Capacity: 47500 Btu/hr
• Motor HP: 1/4 hp
• Motor RPM: 825 rpm
