ALLIED AIR 16G53 4HP15L Series High-Efficiency Louvered Split Heat Pump System

Product Description

The ALLIED AIR 16G53 is designed for heating and cooling needs. This unit belongs to the 4HP15L series and has a nominal capacity of three and a half tons. It operates on a power source of two hundred eight to two hundred thirty VAC, single-phase, at sixty Hz. The system is compatible with R-410A refrigerant.

• Nominal capacity of 3.5 tons
• Operates on 208/230 VAC, 1 phase, 60 Hz power source
• Utilizes a high-efficiency scroll compressor

Product Highlights

This heat pump system is suitable for both residential and commercial applications. It promotes energy savings when paired with compatible units and features a durable design.

Product Information

Standard Information

• Brand: ALLIED AIR
• MPN: 16G53

Technical Specifications

• Series: 4HP15L
• Nominal Capacity: 3.5 ton
• Heating Capacity: 39500 Btu/hr
• Cooling Capacity: 42000 Btu/hr
• Power Source: 208/230 VAC, 1 phase, 60 Hz
• EER Rating: 12
• HSPF Rating: 8.2
• SEER Rating: 14
• COP Rating: 3.2
• Compressor Type: High-Efficiency Scroll
• Refrigerant Type: R-410A
• Suction Line Size: 7/8 inches
• Discharge Line Size: 3/8 inches
• Fuse Size: 45 A
• Temperature Rating: 125 degrees F
• Sound Level: 79 dBA
• Dimensions: 32-1/4 inches W x 32-1/4 inches D x 37-1/4 inches H
• Type: High-Efficiency Louvered
• Motor HP: 1/4 hp
• Motor RPM: 825 rpm
• Material: Galvanized Steel
