ALL-SOURCE 25301 Refrigerant Leak Detector

Product Description

The ALL-SOURCE 25301 is a refrigerant leak detector suitable for both residential and commercial use. It uses a positive ion emission heated diode technology to identify halogen-based refrigerant leaks effectively. Key features include automatic zero balance control and a sensor calibration system that helps in detecting leaks of different sizes.

• Detects CFC, HFC, and HCFC non-flammable refrigerants.
• Features automatic zero balance control for accurate readings.
• Includes a probe with built-in filter for extended use.

Product Highlights

This device is essential for HVAC professionals and technicians who need to ensure that refrigeration systems are leak-free. With a response time of just one second, it provides quick and reliable detection.

Product Information

Standard Information

• Power Supply: 12 VDC, rechargeable sealed lead acid battery with a wall adapter
• Battery Life: Approximately 3 hours

Technical Specifications

• Nominal Leak Range: 0.006 oz/yr (stationary), 0.1 oz/yr (moving probe per SAE J2791)
• Operating Temperature: 32°F to 104°F (0°C to 40°C)
• Warm Up Time: Approximately 2 minutes
• Response Time: 1 second
• Probe Length: 4.5 feet
• Dimensions: 10.5 inches x 8.3 inches x 5.4 inches
