Alfa Laval 242227 90 Degree Bend 2 in 304 Ss Tri Weld X Tri Clamp

Product Description

The ALFA LAVAL 242227 is a 90-degree pipe bend fitting designed for sanitary and industrial piping systems. Constructed from 304 stainless steel, this fitting connects a tri-clamp end to a tri-weld end, allowing technicians to transition between clamped and welded connections within the same line. The 2-inch nominal size suits a wide range of process piping configurations. Plumbers, pipefitters, and sanitary process technicians install this type of fitting where directional changes are required without sacrificing connection integrity or material compatibility.

This fitting is suited for use in food processing, beverage, dairy, pharmaceutical, and general industrial fluid handling systems where sanitary-grade stainless steel fittings are required. The tri-clamp end accepts standard tri-clamp ferrules and gaskets for quick-disconnect service, while the tri-weld end is butt-welded directly into the process line. It is appropriate for both new installations and retrofit applications requiring a 90-degree turn in a 2-inch sanitary pipeline.

Key Features

• 304 stainless steel construction for corrosion resistance in wet and chemical environments
• 90-degree bend angle for directional changes in process piping runs
• 2-inch nominal size fits standard sanitary pipeline configurations
• Tri-weld end for permanent, leak-tight butt-weld integration into process lines
• Tri-clamp end for quick-disconnect service and easy maintenance access
• Dual-end configuration eliminates the need for additional adapters at the transition point

Compatibility

Designed as an OEM-style replacement or direct-fit component for 2-inch sanitary tri-clamp and tri-weld piping systems using standard sanitary ferrule dimensions.

Installation Notes

Installation of this fitting should be performed by a licensed pipefitter or qualified sanitary process technician. Depressurize and drain the system completely before removing or installing any fitting. The tri-weld end requires proper purge-back TIG welding to maintain sanitary weld quality and avoid oxidation on the inside diameter. Ensure the tri-clamp end is mated with a compatible gasket and clamp rated for the system operating pressure and temperature before returning the line to service.

Technical Specifications

• Material: 304 Stainless Steel
• Nominal Size: 2 inches
• Bend Angle: 90 degrees
• End Connections: Tri Weld x Tri Clamp

Standard Information

• Brand: ALFA LAVAL
• Manufacturer Part Number: 242227
