Alarm Controls Corporation ZP-4 Exit Push Button Led

Product Description

The Alarm Controls Corporation ZP-4 is a screened exit push button station equipped with four red LEDs and dual-voltage compatibility at 12 and 24 volts. This type of device is mounted at egress points to provide a lighted, clearly visible request-to-exit signal for access control systems. The screened face prevents casual or accidental actuation while keeping the button accessible for authorized users. Installation is typically performed by a licensed low-voltage or electronic security technician as part of a broader door access control or egress management system.

The ZP-4 is suited for commercial and light-industrial applications where controlled egress is required at secured doors. The dual 12 and 24 volt operating range allows the device to integrate with a wide range of access control panels without requiring a dedicated power supply voltage. The four red LEDs provide a visible status indicator at the button location, aiding both users and service technicians in confirming system activity. Typical installations include office suites, server rooms, warehouses, and other facilities requiring monitored exit points.

Key Features

• Four red LEDs provide visible status indication at the egress point
• Dual-voltage operation at 12 and 24 volts for broad panel compatibility
• Screened face reduces risk of accidental actuation
• Designed for access control and request-to-exit applications
• Single-unit packaging for straightforward field replacement or new installation

Compatibility

Designed as an OEM-style exit push button for commercial access control and request-to-exit systems operating at 12 or 24 volts DC.

Installation Notes

Installation should be performed by a qualified low-voltage or electronic security technician in accordance with applicable local codes and NFPA 70 (NEC) requirements for low-voltage wiring. De-energize the access control panel and associated power supply before making any wiring connections. Verify the system operating voltage matches the ZP-4 input range before powering up. Mount the device at the appropriate egress height per local accessibility and building codes.
