Airrex HSC-60R 220/3 Portable Spot Cooler 60000 Btu 5 Ton

Product Description

The AIRREX HSC-60R 220/3 is a self-contained, air-cooled portable spot cooler rated at 60,000 BTU/h (5 tons) of cooling capacity. It operates on a 220-volt, 3-phase, 60 Hz power supply and draws 18.5 amps under load. The unit uses R-454B refrigerant, an eco-friendly lower-GWP alternative to legacy refrigerants. Designed for industrial and commercial environments, it delivers targeted spot cooling without the need for permanent ductwork or a fixed refrigerant circuit. Licensed HVAC technicians and industrial facilities crews are the typical installers and operators of this class of equipment.

The HSC-60R 220/3 is suited for large-scale temporary or permanent spot cooling applications including industrial production floors, warehouse spaces, server rooms, repair shops, outdoor event structures, and construction sites. Its hardwired 3-phase connection makes it appropriate for facilities with existing 3-phase distribution panels. The unit is rated to operate in ambient air temperatures from 65 degrees F to approximately 113-118 degrees F, making it viable in hot process environments and summer outdoor deployments. Locking casters allow repositioning without disassembly.

Key Features

• 60,000 BTU/h (5-ton) cooling output for large-area or high-heat-load spot cooling
• R-454B refrigerant provides a lower global-warming-potential alternative to R-410A
• 220V 3-phase 60 Hz power supply at 18.5 amps for compatibility with industrial electrical services
• Wide operating ambient range: 65 degrees F to approximately 113-118 degrees F
• Hardwired connection for stable, dedicated power in permanent or semi-permanent installs
• Locking caster wheels for repositioning across flat surfaces without special equipment

Compatibility

Designed for use on 220-volt, 3-phase, 60 Hz electrical services. Intended for industrial and commercial spot cooling applications requiring a self-contained, portable air-cooled unit in the 5-ton class.

Installation Notes

Installation and electrical connection should be performed by a licensed electrician or qualified HVAC technician in accordance with the National Electrical Code (NEC) and all applicable local codes. Verify that the facility electrical panel provides a dedicated 220V 3-phase circuit sized for the unit's current draw before making any connections. The unit is hardwired and uses no standard plug, so confirm breaker sizing and wire gauge with the equipment documentation prior to termination. Always power down and lock out the circuit before servicing the unit or making any adjustments to the refrigerant circuit.

Technical Specifications

• Cooling Capacity: 60,000 BTU/h (5 tons)
• Refrigerant: R-454B
• Power Supply: 220V 3-phase 60 Hz
• Current Consumption: 18.5 amps
• Operating Ambient Range: 65 degrees F to 113-118 degrees F
• Connection Type: Hardwired
• Dimensions (W x D x H): 29 inches x 55 inches x 58 inches
• Weight: 628 pounds

Standard Information

• Brand: AIRREX
• Manufacturer Part Number: HSC-60R 220/3
