Airex TRS-575-G AIREX TITAN OUTLET TRS Wall Penetration Seal Outlet 9.96 in H x 5.97 in W x 7.5 in L

Product Description

The Airex TRS-575-G is a wall penetration seal outlet designed for HVAC systems. This device helps enhance HVACR equipment performance by providing protection from various environmental elements. It features a positive gasket seal that minimizes air leakage, reduces moisture damage to walls, and improves energy efficiency.

• Protects HVAC equipment from weather damage.
• Improves indoor air quality with reduced moisture.
• Meets various building and energy codes.

Product Highlights

The TRS-575-G is engineered with wall isolation and anti-vibration features. It includes a corrosion-resistant hose clamp and installation hardware for long-lasting performance.

Product Information

Standard Information

• Brand: Airex
• MPN: TRS-575-G

Technical Specifications

• Material: Elastomeric Sleeve
• Size: 9.96 inches H x 5.97 inches W x 7.5 inches L
• Color: Gray
• Domestic/Import: Domestic
• Series: TRS
• Suitable For Use With: 5/8 in, 3/4 in, 7/8 in tubing with 3/4 in insulation wall thickness or 1-1/8 in tubing with 1/2 in insulation wall thickness
• Type: Outlet
