Airex pm16202 Pleated Air Filter 16x20x2 Merv 10

Product Description

The AIREX pm16202 is a MERV 10 pleated air filter measuring 16 x 20 x 2 inches, designed for forced-air HVAC systems in residential, commercial, and industrial applications. The filter media is a 100% hydrophobic, synthetic polyolefin material that is electrostatically charged to attract and capture airborne contaminants. Filtration efficiency is rated at 65-70% for particles in the 5-10 micron range. Initial static resistance for the 2-inch depth is 0.26 inches water gauge at 500 feet per minute face velocity. The rigid beverage board frame is moisture resistant and supports pleat spacing integrity through bonded internal support members on both sides of each pleat. The filter pack is bonded to the inside periphery of the frame to eliminate air bypass.

This filter is suited for commercial, industrial, and residential forced-air systems where mid-range particulate control is required. The MERV 10 rating makes it appropriate for applications targeting pollen, mold spores, pet dander, fine dust, and similar airborne particulates. The electrostatically charged Kimberly-Clark Hydrophobic Polyolefin media provides extended service life compared to standard fiberglass panels. Its construction qualifies for LEED point consideration and supports reduced energy consumption through lower initial resistance. The filter is available in 1-inch, 2-inch, and 4-inch depths, with special sizes available upon request.

Key Features

• MERV 10 rating: 65-70% efficiency at 5-10 micron particle size
• Kimberly-Clark 100% hydrophobic, electrostatically charged synthetic polyolefin media
• Initial resistance of 0.26 inches water gauge at 500 FPM for 2-inch depth
• Moisture-resistant, rigid beverage board frame with bonded pleat support members on both sides
• Filter pack bonded to frame interior to prevent air bypass
• Heavy expanded wire media support grid with minimum 93% open area, bonded to prevent media oscillation
• UL 900 listed, flammability class 2 per UL 217V
• Qualifies for LEED points in applicable green building projects

Compatibility

Designed as a direct-fit replacement for standard 16 x 20 x 2 inch filter slots in residential, commercial, and industrial forced-air HVAC systems. Available in 1-inch, 2-inch, and 4-inch depths; special sizes are available upon request for non-standard applications.

Installation Notes

HVAC technicians and qualified service professionals should power down the air handling unit before replacing the filter. Install with airflow direction arrows on the frame oriented toward the blower. Ensure the filter fits flush within the filter rack or housing to prevent air bypass around the frame edges. Follow local mechanical codes and the equipment manufacturer guidelines for filter change intervals based on system load and environment.

Technical Specifications

• Filter Size: 16 x 20 x 2 inches
• MERV Rating: 10
• Filtration Efficiency: 65-70% at 5-10 micron
• Initial Resistance: 0.26 inches water gauge at 500 FPM (2-inch depth)
• Filter Media: Kimberly-Clark Hydrophobic Polyolefin, 100% synthetic, electrostatically charged
• Frame Material: Moisture-resistant rigid beverage board
• Media Support Grid: Heavy expanded wire, minimum 93% open area
• Available Depths: 1 inch, 2 inches, 4 inches
• Certifications: UL 900, UL 217V flammability class 2; LEED point eligible

Standard Information

• Brand: AIREX
• Manufacturer Part Number: pm16202
